Perfect For FTTH deployment, fiber maintenance, and network troubleshooting.
The DS-350 Optical Fiber Identifier (OFI) is a compact, high-sensitivity device designed for live fiber identification without interrupting network service. Perfect for FTTH deployment, fiber maintenance, and network troubleshooting.
| Parameter | Specification |
|---|---|
| Model | DS-350 |
| Wavelength Range | 800–1700nm |
| Detector Type | InGaAs |
| Adapter Types | 0.25 / 0.9 / 2.0 / 3.0 mm |
| Signal Frequency | CW, 270Hz, 1kHz, 2kHz |
| Detection Range | -40 ~ +10 dBm |
| Insertion Loss | ≤1dB |
| Battery | 3.7V / 500mAh |
| Working Time | 24 Hours |
| Operating Temp | -10°C ~ +50°C |
What is an optical fiber identifier?
A tool used to detect signal presence and direction in live fiber.
Is DS-350 non-destructive?
Yes, it works without disconnecting fiber.
Can it detect signal direction?
Yes, via LED indicators.
Looking for a reliable and cost-effective fiber identifier?
